LM239DG

ON SEMICONDUCTOR  LM239DG  模拟比较器, 四路, 通用, 4, 1.3 µs, 3V 至 36V, SOIC, 14 引脚

The is a single-supply quad Comparator designed for use in level detection, low-level sensing and memory applications. The device offers 130mV typical at 4mA low output saturation voltage, 25nA typical low input bias current and ±5nA typical low input offset current.

.

Low input offset voltage

.

Input common mode voltage range to GND

.

TTL and CMOS compatible

.

ESD clamps on the inputs increase reliability without affecting device operation
