LTC3525ISC6-3.3#TRMPBF

LINEAR TECHNOLOGY  LTC3525ISC6-3.3#TRMPBF  同步升压开关稳压器, 固定, 850mV-4.5V输入, 3.3V和0.4A输出, SC-70-6

The is a high efficiency synchronous step-up DC/DC Converter with output disconnect that can start up with an input as low as 0.85V. It offers a compact, high efficiency alternative to charge pumps in single cell or dual cell alkaline or Li-Ion applications. Only three small external components are required. The device includes a 0.5R N-channel MOSFET switch and a 0.8R P-channel synchronous rectifier. Peak switch current ranges from 150 to 400mA, depending on load, providing enhanced efficiency. Quiescent current is an ultralow 7µA. Other features include <1µA shutdown current, antiringing control and thermal shutdown.

.

Up to 95% Efficiency

.

Output disconnect and inrush current limit

.

Only three external components

.

VIN >VOUT Operation

.

Antiringing control

.

Short-circuit and overtemperature protection

.

Very low profile of 1mm

.

<1µA Shutdown current
