LTC2366CS6#PBF

LINEAR TECHNOLOGY  LTC2366CS6#PBF  模数转换器, 12 bit, 3 MSPS, 单, 2.35 V, 3.6 V, TSOT-23

The is a 12-bit serial sampling Analog-to-digital Converter ADC that draws only 2.6mA from a single 3V supply. This high performance device includes a high dynamic range sample-and-hold and a high speed serial interface. The full-scale input is 0V to VDD or VREF. Outstanding AC performance includes 72dB SINAD and -80dB THD at sample rates of 3Msps. The serial interface provides flexible power management and allows maximum power efficiency at low throughput rates. The serial interface and extremely high sample rate-to-power ratio make the ADC ideal for compact, low power and high speed systems. The high impedance single-ended analog input and the ability to operate with reduced spans allow direct connection to sensors and transducers in many applications eliminating the need for gain stages.

.

No data latency

.

Sleep mode with 0.1µA typical supply current

.

Dedicated external reference

.

SPI/MICROWIRE compatible serial I/O
