LTC1608ACG#PBF

LINEAR TECHNOLOGY  LTC1608ACG#PBF  模数转换器, 16 bit, 500 kSPS, 双 +/-, -4.75 V, 5.25 V, SSOP

The is a high speed sampling Analog-to-digital Converter ADC with shutdown. This high performance device includes a high dynamic range sample-and-hold, a precision reference and a high speed parallel output. Two digitally selectable power shutdown modes provide power savings for low power systems. The unique differential input sample-and-hold can acquire single-ended or differential input signals up to its 15MHz bandwidth. The 68dB common mode rejection allows users to eliminate ground loops and common mode noise by measuring signals differentially from the source. The ADC has µP compatible,16-bit parallel output port. There is no pipeline delay in conversion results. A separate convert start input and a data ready signal BUSY ease connections to FlFOs, DSPs and microprocessors.

.

No pipeline delay

.

No missing codes over temperature

.

Nap and sleep shutdown modes

.

Operates with internal 15ppm/°C reference or external reference

.

True differential inputs reject common mode noise

.

Pin compatible with the LTC1604
