LQP15MN15NG02D

MURATA  LQP15MN15NG02D  表面贴装高频电感器, LQP15M系列, 15 nH, ± 2%, 0402 [1005 公制], 3.3 GHz, 1.8 ohm

固定器

立创商城:
15nH ±2% 1.8Ω

得捷:
FIXED IND 15NH 90MA 1.8 OHM SMD

欧时:
Murata LQP15M 系列 LQP15MN15NG02D 15 nH ±2% 铁氧体 多层贴片式电感器, 0402 1005M封装, SRF: 3.3GHz Q: 13

e络盟:
MURATA  LQP15MN15NG02D  表面贴装高频电感器, LQP15M系列, 15 nH, ± 2%, 0402 [1005 公制], 3.3 GHz, 1.8 ohm

艾睿:
Use this rf chip LQP15MN15NG02D surface mount inductor from Murata to make any circuit look clean and compact. This SMD inductor has a minimum operating temperature of -40 °C and a maximum of 85 °C. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components. Its test frequency is 500M Hz, while its minimum self-resonant frequency is 3.3G Hz. This SMD inductor has a maximum DC current of 90m A with a maximum resistance of 1.8 Ohm. It has an inductance of 15n H. This device is made with thin film technology. It has a tolerance of 2%. This product is 1.1 mm long, 0.45 mm tall and 0.6 mm deep.

安富利:
Ind RF Chip Thin Film 15nH 2% 500MHz 13Q-Factor 90mA 0402 Paper T/R

Verical:
Inductor RF Chip Unshielded Thin Film 0.015uH 2% 500MHz 13Q-Factor Non Magnetic 0.09A 1.8Ohm DCR 0402 T/R

儒卓力:
**LQP15MN 15nH 90mA 2% TFT **

Win Source:
FIXED IND 15NH 90MA 1.8 OHM SMD
