LQP03TN2N0B02D

MURATA  LQP03TN2N0B02D  表面贴装高频电感器, LQP03TN系列, 2 nH, ± 0.1nH, 0201 [0603 公制], 12.5 GHz, 0.15 ohm

固定器

得捷:
FIXED IND 2NH 600MA 150 MOHM SMD

立创商城:
2nH ±0.1nH 150mΩ

欧时:
### Murata 0201 LQP03TN_02 系列片状电感器LQP03TN_02 超小型薄型片式电感器，带薄膜技术结构。 提供各种电感值，可实现无调谐装配。 高频率范围时的高 Q 由于低杂散电容和窄电感分布产生的高自谐振频率可在高频电路（例如电信设备）中提供稳定的电感 ### 应用：-移动电话的高频率电路，如 PA、ANT、VCO、SAW 等。 移动电话 “蓝牙” W-LAN 一般高频电路 ### SMT 0201 电感器（扼流圈）

贸泽:
Fixed Inductors 2nH 0.1nH 500MHz

e络盟:
高频电感器, 2 nH, LQP03TN系列, 600 mA, 0201 [0603 公制], 薄膜, 0.15 ohm

艾睿:
This rf chip LQP03TN2N0B02D surface mount inductor from Murata is available in all standard chip sizes in multilayer thick film and thin film deposition and wire wound styles. This SMD inductor has an operating temperature range of -55 °C to 125 °C. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. This product is 0.63 mm long, 0.33 mm tall and 0.33 mm deep. Its test frequency is 500M Hz, while its minimum self-resonant frequency is 12.5G Hz. It has an inductance of 2n H. This SMD inductor has a maximum DC current of 600m A with a maximum resistance of 150m Ohm. This device utilizes thin film technology.

安富利:
Ind RF Chip Thin Film 2nH 0.1nH 500MHz 14Q-Factor 600mA 0201 Paper T/R

Chip1Stop:
Inductor RF Chip Thin Film 2nH 0.1nH 500MHz 14Q-Factor 600mA 150mOhm DCR 0201 Paper T/R

Verical:
Inductor RF Chip Unshielded Thin Film 2nH 0.1nH 500MHz 14Q-Factor Ceramic 600mA 150mOhm DCR 0201 T/R

Newark:
# MURATA  LQP03TN2N0B02D  Surface Mount High Frequency Inductor, LQP03TN Series, 2 nH, 0.1nH, 0201 [0603 Metric], 12.5 GHz

儒卓力:
**LQP03TN 2,0nH 600mA 0,1nH TFT **

Win Source:
2nH Unshielded Thin Film Inductor 600mA 150 mOhm Max 0201 0603 Metric
