LQH55DN330M03L

MURATA  LQH55DN330M03L  表面贴装高频电感器, LQH55D系列, 33 µH, ± 20%, 2220 [5650 公制], 12 MHz, 0.32 ohm

Murata 2220 LQH55D 系列线绕扼流圈

LQH55D 系列线绕器，用于扼流圈应用

使用高性能厚线绕技术。

低直流电阻、大电流容量和大电感

用于直流-直流转换器和直流电源电路

### 表面安装 2220 电感器（扼流圈）

得捷:
FIXED IND 33UH 900MA 448MOHM SMD

立创商城:
33uH ±20% 900mA 448mΩ

欧时:
Murata LQH55D 系列 33 μH 绕线贴片电感器 LQH55DN330M03L, ±20%容差, 900mA Idc, 320mΩ最大直流电阻

贸泽:
固定电感器 33uH 20%

e络盟:
高频电感器, 33 µH, LQH55D系列, 900 mA, 2220 [5650 公制], 绕线, 0.32 ohm

艾睿:
This power chip LQH55DN330M03L surface mount inductor from Murata is ideal for saving valuable space on a PCB. This SMD inductor has a minimum operating temperature of -40 °C and a maximum of 80 °C. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery. This SMD inductor has a maximum DC current of 900m A with a maximum resistance of 448m Ohm. This product is 6 mm long, 5 mm tall and 5.3 mm deep. It has an inductance of 33u H. Its test frequency is 1M Hz, while its minimum self-resonant frequency is 12M Hz. It has a tolerance of 20%. This device is made with wirewound technology.

安富利:
Ind Power Chip Unshielded Wirewound 33uH 20% 1MHz Ferrite 900mA 2220 Embossed T/R

Chip1Stop:
Inductor Power Chip Unshielded Wirewound 33uH 20% 1MHz Ferrite 900mA 448mOhm DCR 2220 Embossed T/R

TME:
Inductor: wire; SMD; 2220; 33uH; 900mA; 0.32Ω; 5.7x5x4.7mm; ±20%

Verical:
Inductor Power Chip Unshielded Wirewound 33uH 20% 1MHz Ferrite 0.9A 0.448Ohm DCR 2220 T/R

Newark:
# MURATA  LQH55DN330M03L  Surface Mount High Frequency Inductor, LQH55D Series, 33 µH, 900 mA, 2220 [5650 Metric], Wirewound

儒卓力:
**LQH55DN 33uH 900mA 20% WWT **

Win Source:
33μH Unshielded Wirewound Inductor 900mA 448 mOhm Max 2220 5750 Metric
