LQG18HNR10J00D

MURATA  LQG18HNR10J00D  表面贴装高频电感器, LQG18HN系列, 100 nH, ± 5%, 0603 [1608 公制], 800 MHz, 0.9 ohm

固定器

欧时:
Murata LQG18H 系列 100 nH 绕线贴片电感器 LQG18HNR10J00D, ±5%容差, 300mA Idc Q:12, 900mΩ最大直流电阻

得捷:
FIXED IND 100NH 300MA 900MOHM SM

立创商城:
100nH ±5% 900mΩ

贸泽:
Fixed Inductors 0603 AIR CORE .1uH 5% TOL

e络盟:
高频电感器, 100 nH, LQG18HN系列, 300 mA, 0603 [1608 公制], 多层, 0.9 ohm

艾睿:
Does your electronic circuit design require filtering, power supplies, and other similar functions? Then this rf chip LQG18HNR10J00D surface mount inductor from Murata is perfect for you! This SMD inductor has an operating temperature range of -40 °C to 85 °C. In order to guarantee safe delivery and allow for quick mounting of this component after delivery, it will be enclosed in tape and reel packaging during shipment. This SMD inductor has a maximum DC current of 350m A with a maximum resistance of 900m Ohm. This product is 1.75 mm long, 0.95 mm tall and 0.95 mm deep. It has a tolerance of 5%. Its test frequency is 100M Hz, while its minimum self-resonant frequency is 800M Hz. It has an inductance of 100n H. This device utilizes multi-layer technology.

Chip1Stop:
Inductor RF Chip Multi-Layer 100nH 5% 100MHz 12Q-Factor Air 300mA 900mOhm DCR 0603 Paper T/R

TME:
Inductor: ceramic; SMD; 0603; 100nH; 350mA; 0.9Ω; ftest:100MHz; Q:12

Verical:
Inductor RF Chip Unshielded Multi-Layer 0.1uH 5% 100MHz 12Q-Factor Air 0.35A 0.9Ohm DCR 0603 T/R

Newark:
# MURATA  LQG18HNR10J00D  Surface Mount High Frequency Inductor, LQG18HN Series, 100 nH, 300 mA, 0603 [1608 Metric]

儒卓力:
**LQG18HN 0,1uH 300mA 5% MLT **

Win Source:
100nH Unshielded Multilayer Inductor 300mA 900 mOhm Max 0603 1608 Metric
