LQG15HN27NJ02D

MURATA  LQG15HN27NJ02D  表面贴装高频电感器, LQG15HN系列, 27 nH, ± 5%, 0402 [1005 公制], 1.6 GHz, 0.67 ohm

固定器

欧时:
Murata LQG15HN 系列 LQG15HN27NJ02D 27 nH ±5% 多层贴片式电感器, 0402 1005M封装 Q: 8 300mA dc 670mΩ Rdc

得捷:
FIXED IND 27NH 300MA 670MOHM SMD

立创商城:
27nH ±5% 670mΩ

e络盟:
高频电感器, 27 nH, LQG15HN系列, 300 mA, 0402 [1005 公制], 多层, 0.67 ohm

艾睿:
Use this rf chip LQG15HN27NJ02D surface mount inductor from Murata to make any circuit look clean and compact. This SMD inductor has a minimum operating temperature of -55 °C and a maximum of 125 °C. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery. It has an inductance of 27n H. It has a tolerance of 5%. This device is made with multi-layer technology. This product is 1.05 mm long, 0.55 mm tall and 0.55 mm deep. This SMD inductor has a maximum DC current of 300m A with a maximum resistance of 670m Ohm. Its test frequency is 100M Hz, while its minimum self-resonant frequency is 1.6G Hz.

安富利:
Ind RF Chip Multi-Layer 27nH 5% 100MHz 8Q-Factor Air 300mA 0402 Paper T/R

Chip1Stop:
Inductor RF Chip Multi-Layer 27nH 5% 100MHz 8Q-Factor Air 300mA 670mOhm DCR 0402 T/R

TME:
Inductor: ceramic; SMD; 0402; 27nH; 300mA; 0.67Ω; Q:8; ftest:100MHz

Verical:
Inductor RF Chip Unshielded Multi-Layer 0.027uH 5% 100MHz 8Q-Factor Air 0.3A 0.67Ohm DCR 0402 T/R

Newark:
# MURATA  LQG15HN27NJ02D  Surface Mount High Frequency Inductor, LQG15HN Series, 27 nH, 300 mA, 0402 [1005 Metric]

儒卓力:
**LQG15HN 27nH 300mA 5% MLT **
