LQG15HN2N0S02D

MURATA  LQG15HN2N0S02D  表面贴装高频电感器, LQG15HN系列, 2 nH, ± 0.3nH, 0402 [1005 公制], 6 GHz, 0.12 ohm

固定器

得捷:
FIXED IND 2NH 900MA 120 MOHM SMD

立创商城:
2nH ±0.3nH 90mΩ

欧时:
Murata LQG15H 系列 2 nH 绕线贴片电感器 LQG15HN2N0S02D, ±0.3nH容差, 300mA Idc Q:8, 120mΩ最大直流电阻

e络盟:
MURATA  LQG15HN2N0S02D  表面贴装高频电感器, LQG15HN系列, 2 nH, ± 0.3nH, 0402 [1005 公制], 6 GHz, 0.12 ohm

艾睿:
Does your electronic circuit design require filtering, power supplies, and other similar functions? Then this rf chip LQG15HN2N0S02D surface mount inductor from Murata is perfect for you! This SMD inductor has an operating temperature range of -55 °C to 125 °C. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery. This SMD inductor has a maximum DC current of 300m A with a maximum resistance of 120m Ohm. It has an inductance of 2n H. This product is 1.05 mm long, 0.55 mm tall and 0.55 mm deep. Its test frequency is 100M Hz, while its minimum self-resonant frequency is 6G Hz. This device utilizes multi-layer technology.

安富利:
Ind RF Chip Multi-Layer 2nH 0.3nH 100MHz 8Q-Factor Air 300mA 0402 Paper T/R

Chip1Stop:
Inductor RF Chip Multi-Layer 2nH 0.3nH 100MHz 8Q-Factor Air 300mA 120mOhm DCR 0402 T/R

Verical:
Inductor RF Chip Unshielded Multi-Layer 0.002uH 0.3nH 100MHz 8Q-Factor Air 0.9A 0.09Ohm DCR 0402 T/R

儒卓力:
**LQG15HN 2,0nH 300mA 0,3nH MLT **
