LM3900DR

翻两番诺顿运算放大器 QUADRUPLE NORTON OPERATIONAL AMPLIFIERS

description

These devices consist of four independent, high gain frequency-compensated Norton operational

amplifiers that were designed specifically to operate from a single supply over a wide range of

voltages. Operation from split supplies is also possible. The low supply current drain is essentially independent of the magnitude of the supply voltage. These devices provide wide band width and large output voltage swing.

The LM2900 is characterized for operation from –40°C to 85°C, and the LM3900 is characterized

for operation from 0°C to 70°C.

Wide Range of Supply Voltages, Single or Dual Supplies

Wide Bandwidth

Large Output Voltage Swing

Output Short-Circuit Protection

nternal Frequency Compensation

Low Input Bias Current

Designed to Be Interchangeable With National Semiconductor LM2900 and LM3900, Respectively ption
