1.5A调压器
The is capable of supplying in excess of 1.5A over 1.2V to 37V output voltage range. It is exceptionally easy to use and require only two external resistors to set the output voltage. the LM317T offers full overload protection available only in IC"s.
- .
- Output is short-circuit protected
- .
- 80 dB ripple rejection
- .
- Current limit constant with temperature
- .
- Adjustable output down to 1.2V
No capacitors are needed unless the device is situated more than 6 inches from the input filter capacitors in which case an input bypass is needed
电源电压DC 40.0V max
额定电流 1.50 A
输出接口数 1
输出电压 1.2V ~ 37V
输出电流 1.5 A
供电电流 10 mA
针脚数 3
静态电流 60.0 µA
输出电容类型 Ceramic
跌落电压 170 mV
调节输出数 1
输入电压Max 40 V
输入电压Min 4.2 V
输出电压Max 37 V
输出电压Min 1.2 V
输出电流Max 1.5 A
工作温度Max 125 ℃
工作温度Min -40 ℃
精度 ±1 %
输入电压 4.2V ~ 37V
安装方式 Through Hole
引脚数 3
封装 TO-220-3
封装 TO-220-3
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tube
RoHS标准 Non-Compliant
含铅标准 Contains Lead
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/06/15
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
LM317AT TI 德州仪器 | 当前型号 | 当前型号 |
LM317AT/NOPB 德州仪器 | 完全替代 | LM317AT和LM317AT/NOPB的区别 |
LM317T/NOPB 德州仪器 | 完全替代 | LM317AT和LM317T/NOPB的区别 |
LM317T 意法半导体 | 类似代替 | LM317AT和LM317T的区别 |
