LM1117LD-3.3/NOPB

TEXAS INSTRUMENTS  LM1117LD-3.3/NOPB  稳压器, 固定LDO, 15V输入, 1.2V压差, 3.3V/800mA输出, WSON-8

LDO（低压降）线性稳压器，600mA 至 800mA，Texas Instruments

### LDO（低压降）线性稳压器，Texas Instruments

低压降或 LDO 为线性电压稳压器。 我们有多种系列的线性稳压器。 LDO 稳压器可在输入 - 输出差分电压较小时运行。 LDO 电压稳压器可提供快速瞬态响应、宽输入电压范围、低静态电流、低噪声、高 PSRR。

得捷:
IC REG LINEAR 3.3V 800MA 8WSON

立创商城:
LM1117LD-3.3/NOPB

德州仪器TI:
800-mA 15-V linear voltage regulator

欧时:
### LDO（低压降）线性稳压器，600mA 至 800mA，Texas Instruments### LDO（低压降）线性稳压器，Texas Instruments低压降或 LDO 为线性电压稳压器。 我们有多种系列的线性稳压器。 LDO 稳压器可在输入 - 输出差分电压较小时运行。 LDO 电压稳压器可提供快速瞬态响应、宽输入电压范围、低静态电流、低噪声、高 PSRR。

贸泽:
LDO Voltage Regulators 800mA LDO Linear Reg

e络盟:
稳压器, 固定LDO, 15V输入, 1.2V压差, 3.3V/800mA输出, WSON-8

艾睿:
This LDO LM1117LD-3.3/NOPB linear regulator from Texas Instruments acts like a variable resistor to maintain a steady voltage level. Its typical dropout voltage at current is 1.1@100mA|1.15@500mA|1.2@800mA V. It has an overall accuracy of ±1 %. This voltage regulation device&s;s single output can produce a current up to 0.8 A. Supply your circuit with sufficient power by implementing this, which does not exceed 15 V. With a fixed output that has a voltage of 3.3 V, this is power management at its best. At a load regulation of 1mVTyp and line regulation of 1mVTyp a constant current can be produced at the output of your circuit. This component will be shipped in tape and reel packaging for effective mounting and safe delivery. The maximum dropout voltage is 1.2@100mA|1.25@500mA|1.3@800mA V. Its polarity is positive. This voltage regulation device has an operating temperature range of 0 °C to 125 °C.

安富利:
LDO Regulator Pos 3.3V 0.8A 8-Pin LLP EP T/R

Chip1Stop:
LDO Regulator Pos 3.3V 0.8A 8-Pin WSON EP T/R

Verical:
LDO Regulator Pos 3.3V 0.8A 8-Pin WSON EP T/R

Newark:
# TEXAS INSTRUMENTS  LM1117LD-3.3/NOPB  V REG LDO 0.8A +3.3V, 1117, LLP-8

DeviceMart:
IC REG LDO 3.3V .8A 8-LLP
