LPV358MX/NOPB

TEXAS INSTRUMENTS  LPV358MX/NOPB  运算放大器, 双路, 152 kHz, 2个放大器, 0.1 V/µs, 2.7V 至 5V, SOIC, 8 引脚

The is a general purpose low power Operational Amplifier with rail-to-rail output. This is another addition to the LMV358 family of commodity op amps. The LPV358 has rail-to-rail output swing capability and the input common-mode voltage range includes ground. It all exhibits excellent speed-power ratio, achieving 5kHz of bandwidth with a supply current of only 9µA. It also allows the designer to place the device closer to the signal source to reduce noise pickup and increase signal integrity. The chips are built with Texas Instrument"s advanced submicron silicon-gate BiCMOS process. The LPV358 has bipolar input and output stages for improved noise performance and higher output current drive.

.

No crossover distortion

.

15µA Low supply current

.

2µV/°C Typical offset drift

.

71dB Typical CMRR

.

Green product and no Sb/Br
