LM2902MX/NOPB

TEXAS INSTRUMENTS  LM2902MX/NOPB  运算放大器, 四路, 1 MHz, 4个放大器, 0.5 V/µs, ± 1.5V 至 ± 16V, SOIC, 14 引脚

The is a quad low power high-gain internally frequency compensated Operational Amplifier designed to operate from a single power supply over a wide range of voltages. Operation from split-power supplies is also possible and the low-power supply current drain is independent of the magnitude of the power supply voltage. Application areas include transducer amplifiers, DC gain blocks and all the conventional op amp circuits which now can be more easily implemented in single power supply systems.

.

Internally frequency compensated for unity gain

.

Input common-mode voltage range includes ground

.

Differential input voltage range equal to the power supply voltage

.

Large output voltage swing 0 to V+ -1.5V

.

Allows direct sensing near GND and VOUT also goes to GND

.

Compatible with all forms of logic

.

Power drain suitable for battery operation

.

In the linear mode the input common-mode, voltage range includes ground and the output voltage

.

Can swing to ground, even though operated from only a single power supply voltage

.

Unity gain cross frequency is temperature compensated

.

Input bias current is also temperature compensated

.

100dB Large DC voltage gain

.

700µA Very low supply current drain

.

45nA Low input biasing current temperature compensated

.

2mV Low input offset voltage

.

5nA Low input offset current

.

Green product and no Sb/Br
