STMICROELECTRONICS LF60CDT-TR 固定电压稳压器, LDO, 3V至16V, 400mV压差, 6V输出, 0.5A输出, TO-252-3
PMIC - 稳压器 - 线性 正 固定 1 输出 500mA DPAK
得捷:
IC REG LINEAR 6V 500MA DPAK
立创商城:
LF60CDT-TR
e络盟:
固定电压稳压器, LDO, 3V至16V, 400mV压差, 6V输出, 0.5A输出, TO-252-3
艾睿:
Make a theoretical system actual by providing stable voltages with this LDO LF60CDT-TR linear regulator from STMicroelectronics. It has an overall accuracy of ±2 %. Its typical dropout voltage at current is 0.2@200mA|0.4@500mA V. This voltage regulation device&s;s single output can produce a current up to 0.5 A. Supply your circuit with sufficient power by implementing this, which does not exceed 16 V. With a fixed output that has a voltage of 6 V, this is power management at its best. Operate at a constant current by utilizing the load regulation of 30mV and line regulation of 30mV. Tape and reel packaging will encase the product during shipment, ensuring safe delivery and enabling quick mounting of components. Its polarity is positive. This voltage regulation device has an operating temperature range of -40 °C to 125 °C. The maximum dropout voltage is 0.35@200mA|0.7@500mA V.
安富利:
LDO Regulator Pos 6V 0.5A 3-Pin2+Tab DPAK T/R
富昌:
LF60 系列 6 V 500 mA 极低压差 稳压器 带抑制 - TO-252
Chip1Stop:
LDO Regulator Pos 6V 0.5A 3-Pin2+Tab DPAK T/R
Newark:
# STMICROELECTRONICS LF60CDT-TR Fixed LDO Voltage Regulator, 3V to 16V, 400mV Dropout, 6Vout, 0.5Aout, TO-252-3
儒卓力:
**LDO VREG 6V 0.5A 2% DPAK **
输出接口数 1
输入电压DC 16.0V max
输出电压 6 V
输出电流 500 mA
供电电流 1mA ~ 12mA
针脚数 3
静态电流 0.7 mA
跌落电压 400 mV
输入电压Max 16 V
输入电压Min 3 V
输出电压Min 6 V
输出电流Max 0.5 A
工作温度Max 125 ℃
工作温度Min -40 ℃
精度 ±2 %
电源电压Max 16 V
电源电压Min 16 V
输入电压 40 V
安装方式 Surface Mount
引脚数 3
封装 TO-252-3
封装 TO-252-3
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Cut Tape CT
制造应用 工业, Power Management, 便携式器材, Industrial, Portable Devices, 电源管理
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/12/17
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
LF60CDT-TR ST Microelectronics 意法半导体 | 当前型号 | 当前型号 |
LF60CDT 意法半导体 | 完全替代 | LF60CDT-TR和LF60CDT的区别 |
NCP4629HDT060T5G 安森美 | 功能相似 | LF60CDT-TR和NCP4629HDT060T5G的区别 |
LF60CPT-TR 意法半导体 | 功能相似 | LF60CDT-TR和LF60CPT-TR的区别 |
