CMOS 运算放大器,LMV/TLV 系列### 运算放大器,Texas Instruments
低电压 CMOS ,LMV/TLV 系列
立创商城:
LMV851MG/NOPB
德州仪器TI:
Single, 5.5-V, 8-MHz, 62-mA output current, low noise 11-nV/√Hz operational amplifier
得捷:
IC OPAMP GP 1 CIRCUIT SC70-5
欧时:
Texas Instruments 运算放大器 LMV851MG/NOPB 精确, 8MHz增益带宽积, 2.7 → 5.5 V单电源电压, 5引脚
贸泽:
Precision Amplifiers LMV851 EVAL BOARD
e络盟:
TEXAS INSTRUMENTS LMV851MG/NOPB 运算放大器, 8 MHz, 1个放大器, 4.5 V/µs, 2.7V 至 5.5V, SC-70, 5 引脚
艾睿:
The infinite open-loop gain, high input impedance and low output impedance of this general purpose amplifier LMV851MG/NOPB OP amp from Texas Instruments produces a large amount of gain. This op amp has a minimum operating temperature of -40 °C and a maximum of 125 °C. It has a single channel per chip. This device uses a single power supply. This device is made with CMOS technology.
安富利:
OP Amp Single GP R-R O/P 5.5V 5-Pin SC-70 T/R
Verical:
Op Amp Single Low Power Amplifier R-R O/P 5.5V 5-Pin SC-70 T/R
Newark:
# TEXAS INSTRUMENTS LMV851MG/NOPB Operational Amplifier, 8 MHz, 1, 4.5 V/ s, 2.7V to 5.5V, SC-70, 5
DeviceMart:
IC AMP EMI LP 8MHZ SGL SC70-5
输出电流 30mA @3.3V
供电电流 430 µA
电路数 1
通道数 1
针脚数 5
共模抑制比 77 dB
输入补偿漂移 400 nV/K
带宽 8 MHz
转换速率 4.50 V/μs
增益频宽积 8 MHz
输入补偿电压 260 µV
输入偏置电流 .1 pA
工作温度Max 125 ℃
工作温度Min -40 ℃
增益带宽 8 MHz
共模抑制比Min 77 dB
电源电压 2.7V ~ 5.5V
电源电压Max 5.5 V
电源电压Min 2.7 V
安装方式 Surface Mount
引脚数 5
封装 SC-70-5
长度 2 mm
宽度 1.25 mm
高度 0.9 mm
封装 SC-70-5
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/06/15
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
LMV851MG/NOPB TI 德州仪器 | 当前型号 | 当前型号 |
LMV851MGX/NOPB 德州仪器 | 类似代替 | LMV851MG/NOPB和LMV851MGX/NOPB的区别 |
LMV851MGE/NOPB 德州仪器 | 类似代替 | LMV851MG/NOPB和LMV851MGE/NOPB的区别 |
LMV851MG 德州仪器 | 功能相似 | LMV851MG/NOPB和LMV851MG的区别 |
