TEXAS INSTRUMENTS LM7301IM5 运算放大器, 单路, 4 MHz, 1个放大器, 1.25 V/µs, 2.2V 至 30V, SOT-23, 5 引脚
The is a rail-to-rail input-output Operational Amplifier offers greater than rail-to-rail input range, full rail-to-rail output swing, large capacitive load driving ability and low distortion. With only 0.6mA supply current, the 4MHz gain-bandwidth of this device supports new portable applications where higher power devices unacceptably drain battery life. The LM7301 can be driven by voltages that exceed both power supply rails, thus eliminating concerns over exceeding the common-mode voltage range. The rail-to-rail output swing capability provides the maximum possible dynamic range at the output. This is particularly important when operating on low supply voltages. Operating on supplies of 1.8 to 32V, the amplifier is excellent for a very wide range of applications in low power systems. Placing the amplifier right at the signal source reduces board size and simplifies signal routing and fits easily on low profile PCMCIA cards.
This device has limited built-in ESD protection, leads should be shorted together or the device placed in conductive foam during storage or handling to prevent electrostatic damage to the MOS gates.
电源电压DC 5.00 V
输出电流 ≤20 mA
供电电流 720 µA
电路数 1
通道数 1
针脚数 5
耗散功率 0.35 W
共模抑制比 70 dB
输入补偿漂移 2.00 µV/K
带宽 4 MHz
转换速率 1.25 V/μs
增益频宽积 4 MHz
输入补偿电压 40 µV
输入偏置电流 103 nA
工作温度Max 85 ℃
工作温度Min -40 ℃
增益带宽 4 MHz
耗散功率Max 350 mW
共模抑制比Min 70 dB
电源电压 2.2V ~ 30V
电源电压Max 32 V
电源电压Min 1.8 V
安装方式 Surface Mount
引脚数 5
封装 SOT-23-5
宽度 1.6 mm
封装 SOT-23-5
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
制造应用 通信与网络, 便携式器材
RoHS标准 Non-Compliant
含铅标准 Contains Lead
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/06/15
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
LM7301IM5 TI 德州仪器 | 当前型号 | 当前型号 |
LM7301IM5/NOPB 德州仪器 | 完全替代 | LM7301IM5和LM7301IM5/NOPB的区别 |
LM7301IM5X/NOPB 德州仪器 | 完全替代 | LM7301IM5和LM7301IM5X/NOPB的区别 |
LMV751M5/NOPB 德州仪器 | 类似代替 | LM7301IM5和LMV751M5/NOPB的区别 |
