Texas Instruments
低电压
得捷:
IC OPAMP VFB 4 CIRCUIT 14TSSOP
立创商城:
LMH6644MT/NOPB
德州仪器TI:
Low Power, 130MHz, 75mA Rail-to-Rail Output Amplifiers
欧时:
Texas Instruments 运算放大器 LMH6644MT/NOPB 四路, 3 → 12 V单电源电压, 14引脚 TSSOP封装
艾睿:
The configuration of this voltage feedback amplifier LMH6644MT/NOPB OP amp from Texas Instruments allows it to take on a variety of different behaviors and characteristics with external components such as resistors, capacitors and inductors. Its typical dual supply voltage is ±3|±5 V, with a minimum of ±1.35 V and maximum of ±6.4 V. This op amp has a minimum operating temperature of -40 °C and a maximum of 85 °C. It has 4 channels per chip. This device is made with bicom technology. This device uses one or two power supplies.
安富利:
OP Amp Quad Volt Fdbk R-R O/P ±6.4V/12.8V 14-Pin TSSOP Rail
Chip1Stop:
OP Amp Quad Volt Fdbk R-R O/P ±6.4V/12.8V 14-Pin TSSOP Rail
Verical:
Op Amp Quad High Speed Amplifier R-R O/P ±6.4V/12.8V 14-Pin TSSOP Tube
Newark:
# TEXAS INSTRUMENTS LMH6644MT/NOPB Operational Amplifier, Quad, 4 Amplifier, 130 MHz, 135 V/µs, 2.7V to 12.8V, TSSOP, 14 Pins
DeviceMart:
IC AMP R-R I/O 3V 130MHZ 14TSSOP
输出电流 70mA @5V
供电电流 2.7 mA
电路数 4
通道数 4
共模抑制比 72 dB
输入补偿漂移 5.00 µV/K
带宽 130 MHz
转换速率 135 V/μs
增益频宽积 130 MHz
输入补偿电压 1 mV
输入偏置电流 20 nA
工作温度Max 85 ℃
工作温度Min -40 ℃
3dB带宽 130 MHz
共模抑制比Min 72 dB
电源电压 2.7V ~ 12.8V
电源电压Max 12.8 V
电源电压Min 2.7 V
安装方式 Surface Mount
引脚数 14
封装 TSSOP-14
长度 5 mm
宽度 4.4 mm
高度 0.9 mm
封装 TSSOP-14
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tube
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/06/15
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
LMH6644MT/NOPB TI 德州仪器 | 当前型号 | 当前型号 |
LMH6644MTX/NOPB 德州仪器 | 完全替代 | LMH6644MT/NOPB和LMH6644MTX/NOPB的区别 |
LMH6644MA 德州仪器 | 完全替代 | LMH6644MT/NOPB和LMH6644MA的区别 |
LMH6644MT 德州仪器 | 类似代替 | LMH6644MT/NOPB和LMH6644MT的区别 |
