LT1221CN8#PBF

LINEAR TECHNOLOGY  LT1221CN8#PBF  运算放大器, 单路, 150 MHz, 1个放大器, 250 V/µs, ± 5V 至 ± 15V, DIP, 8 引脚

The is a very high speed Operational Amplifier with superior DC performance. The LT1221 is stable in a noise gain of 4 or greater. It features reduced input offset voltage, lower input bias currents and higher DC gain than devices with comparable bandwidth and slew rate. The circuit is a single gain stage that includes proprietary DC gain enhancement circuitry to obtain precision with high speed. The high gain and fast settling time make the circuit an ideal choice for data acquisition systems. The circuit is also capable of driving capacitive loads which makes it useful in buffer or cable driver applications.

.

6nV/√Hz Input noise voltage

.

C-Load™ op amp drives capacitive loads

.

600mV Maximum input offset voltage

.

300nA Maximum input bias current

.

300nA Maximum input offset current

.

±12V Minimum output swing into 500W

.

50V/mV, RL = 500W Minimum DC gain
