LT1361CS8#PBF

LINEAR TECHNOLOGY  LT1361CS8#PBF  运算放大器, 双路, 50 MHz, 2个放大器, 800 V/µs, ± 2.5V 至 ± 15V, SOIC, 8 引脚

The is a dual low power high speed Operational Amplifier with outstanding AC and DC performance. The amplifier feature much lower supply current and higher slew rate than devices with comparable bandwidth. The circuit topology is a voltage feedback amplifier with matched high impedance inputs and the slewing performance of a current feedback amplifier. The high slew rate and single stage design provide excellent settling characteristics which make the circuit an ideal choice for data acquisition systems. Each output drives a 500R load to ±13V with ±15V supplies and a 150R load to ±3.2V on ±5V supplies. The amplifier is stable with any capacitive load making them useful in buffer or cable driving applications.

.

5mA Maximum supply current per amplifier

.

Unity-gain stable

.

C-Load™ op amp drives all capacitive loads

.

9nV/√Hz Input noise voltage

.

1mV Maximum input offset voltage

.

1mA Maximum input bias current

.

250nA Maximum input offset current
