LT1358IS8#PBF

LINEAR TECHNOLOGY  LT1358IS8#PBF  运算放大器, 双路, 25 MHz, 2个放大器, 600 V/µs, 5V 至 36V, SOIC, 8 引脚

The is a dual low power high speed Operational Amplifier with outstanding AC and DC performance. The amplifier feature much lower supply current and higher slew rate than devices with comparable bandwidth. The circuit topology is a voltage feedback amplifier with matched high impedance inputs and the slewing performance of a current feedback amplifier. The high slew rate and single stage design provide excellent settling characteristics which make the circuit an ideal choice for data acquisition systems. Each output drives a 500R load to ±12.5V with ±15V supplies and a 150R load to ±3V on ±5V supplies. The amplifier is stable with any capacitive load making them useful in buffer applications.

.

2.5mA Maximum supply current

.

Unity-gain stable

.

C-Load™ op amp drives all capacitive loads

.

8nV/√Hz Input noise voltage

.

600µV Maximum input offset voltage

.

500nA Maximum input bias current

.

120nA Maximum input offset current
