LM158AH/NOPB

低功耗双路运算放大器 8-TO-99 -55 to 125

* Wide Supply Ranges * Single Supply: 3 V to 32 V 26 V for LM2904 * Dual Supplies: ±1.5 V to ±16 V ±13 V for LM2904 * Low Supply-Current Drain, Independent of Supply Voltage: 0.7 mA Typical * Wide Unity Gain Bandwidth: 0.7 MHz * Common-Mode Input Voltage Range Includes Ground, Allowing Direct Sensing Near Ground * Low Input Bias and Offset Parameters * Input Offset Voltage: 3 mV Typical A Versions: 2 mV Typical * Input Offset Current: 2 nA Typical * Input Bias Current: 20 nA Typical A Versions: 15 nA Typical * Differential Input Voltage Range Equal to Maximum-Rated Supply Voltage: 32 V 26 V for LM2904 * Open-Loop Differential Voltage Gain: 100 dB Typical * Internal Frequency Compensation
