LT1885CS#PBF

LINEAR TECHNOLOGY  LT1885CS#PBF  运算放大器, 四路, 2 MHz, 4个放大器, 0.9 V/µs, 5V 至 ± 15V, SOIC, 14 引脚

The is an Operational Amplifier bring high accuracy input performance with rail-to-rail output swing while providing faster response than other precision amplifiers. Input offset voltage is trimmed to less than 50µV and the low drift maintains this accuracy over the operating temperature range. Input bias current is an ultralow 400pA maximum. The amplifier work on any total power supply voltage between 2.7 and 36V fully specified from 5 to ±15V. Output voltage swings to within 40mV of the negative supply and 220mV of the positive supply make these amplifier good choices for low voltage single supply operation. Slew rates of 1V/µs with a supply current of less than 1mA per amplifier give superior response and settling time performance in a low power precision amplifier.

.

0.8mV/°C Maximum offset voltage drift

.

Operates with single or split supplies

.

1 million Minimum open-loop voltage gain

.

Standard pinouts
