超低功率翻两番运算放大器 ULTRA-LOW-POWER QUADRUPLE OPERATIONAL AMPLIFIERS
General Purpose Amplifier 4 Circuit 14-SOIC
得捷:
IC OPAMP GP 4 CIRCUIT 14SOIC
立创商城:
LP2902DR
德州仪器TI:
Quad, 32-V, 100-kHz, low Iq 21-µA/ch, 4-mV offset voltage op amp with -40°C to 85°C operation
艾睿:
Increase functionality to your instrumentation with this general purpose amplifier LP2902DR OP amp from Texas Instruments. Its typical dual supply voltage is ±3|±5|±9|±12|±15 V, with a minimum of ±1.5 V and maximum of ±16 V. This op amp has a temperature range of -40 °C to 85 °C. It has 4 channels per chip. This device uses one or two power supplies. This device utilizes bipolar technology.
安富利:
OP Amp Quad GP ±16V/32V 14-Pin SOIC T/R
Chip1Stop:
Standard Linear AmplifierUltra-Low-Power Quadruple Operational Amplifier OP Amp Quad GP ±16V/32V 14-Pin SOIC T/R
Verical:
Op Amp Quad Low Power Amplifier ±16V/32V 14-Pin SOIC T/R
Win Source:
IC OPAMP GP 100KHZ 14SOIC
输出电流 10mA @5V
供电电流 85 µA
电路数 4
通道数 4
共模抑制比 80 dB
输入补偿漂移 10.0 µV/K
带宽 100 kHz
转换速率 50.0 mV/μs
增益频宽积 100 kHz
输入补偿电压 2 mV
输入偏置电流 2 nA
工作温度Max 85 ℃
工作温度Min -40 ℃
增益带宽 0.1 MHz
共模抑制比Min 80 dB
电源电压 3V ~ 32V
安装方式 Surface Mount
引脚数 14
封装 SOIC-14
封装 SOIC-14
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
LP2902DR TI 德州仪器 | 当前型号 | 当前型号 |
LP2902DG4 德州仪器 | 完全替代 | LP2902DR和LP2902DG4的区别 |
LP2902DRE4 德州仪器 | 完全替代 | LP2902DR和LP2902DRE4的区别 |
LP2902M/NOPB 德州仪器 | 类似代替 | LP2902DR和LP2902M/NOPB的区别 |
