Stellaris® LM3S1332微控制器 Stellaris® LM3S1332 Microcontroller
* 32-bit ARM® Cortex™-M3 50-MHz processor core with System Timer SysTick, integrated Nested Vectored Interrupt Controller NVIC, Memory Protection Unit MPU, and Thumb-2 instruction set * Full-featured debug solution with debug access via JTAG and Serial Wire interfaces, and IEEE 1149.1-1990 compliant Test Access Port TAP controller * 96 KB single-cycle flash and 16 KB single-cycle SRAM * Lower-power battery-backed Hibernation module with Real-Time Clock * 29-57 GPIOs depending on configuration with programmable control for GPIO interrupts and pad configuration * ARM FiRM-compliant Watchdog Timer ; plus four General-Purpose Timer Modules GPTM, each of which provides two 16-bit timers/counters and can be configured to operate independently * 10-bit Analog-to-Digital Converter ADC with three analog input channels and a sample rate of 250 thousand samples/second * Two fully programmable 16C550-type UARTs with IrDA support * Synchronous Serial Interface SSI, supporting operation for Freescale SPI, MICROWIRE, or Texas Instruments synchronous serial interfaces * Three integrated analog comparators configurable for output to initiate an ADC sample sequence, drive an output pin or generate an interrupt * Industrial and extended temperature RoHS-compliant 100-pin LQFP package and industrial-range RoHS-compliant 108-ball BGA package
