Stellaris® 微控制器,Texas InstrumentsStellaris® ARM® Cortex™ 微控制器提供到行业中最强的开发工具、软件、和知识生态系统的直接路径 迁移到 Stellaris 的设计人员将受益于伟大的工具、较小的代码量和出色的性能 ### Stellaris ARM Cortex-M3 微控制器,Texas Instruments
Stellaris® ,Texas Instruments
Stellaris® ARM® Cortex™ 微控制器提供到行业中最强的开发工具、软件、和知识生态系统的直接路径
迁移到 Stellaris 的设计人员将受益于伟大的工具、较小的代码量和出色的性能
立创商城:
LM3S2139-IQC25-A2
得捷:
IC MCU 32BIT 64KB FLASH 100LQFP
欧时:
Texas Instruments Stellaris 系列 MCU 微控制单元 32 bit, ARM Cortex M3, 1xUSB, LQFP-100, LM3S2139-IQC25-A2
贸泽:
ARM微控制器 - MCU Stellaris Cortex M-3 CAN 10-Bit ADC
艾睿:
MCU 32-bit ARM Cortex M3 RISC 64KB Flash 2.5V/3.3V 100-Pin LQFP Tray
安富利:
MCU 32-bit Stellaris ARM Cortex M3 RISC 64KB Flash 2.5V/3.3V 100-Pin LQFP Tray
Chip1Stop:
MCU 32-bit Stellaris ARM Cortex M3 RISC 64KB Flash 2.5V/3.3V 100-Pin LQFP Tray
电源电压DC 2.25V min
时钟频率 25.0MHz max
RAM大小 16K x 8
位数 32
FLASH内存容量 64 KB
UART数量 2
模数转换数ADC 1
工作温度Max 85 ℃
工作温度Min -40 ℃
安装方式 Surface Mount
引脚数 100
封装 LQFP-100
长度 14 mm
宽度 14 mm
高度 1.4 mm
封装 LQFP-100
工作温度 -40℃ ~ 85℃
产品生命周期 Not Recommended for New Designs
包装方式 Tray
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
LM3S2139-IQC25-A2 TI 德州仪器 | 当前型号 | 当前型号 |
LM3S2139-EQC25-A2 德州仪器 | 类似代替 | LM3S2139-IQC25-A2和LM3S2139-EQC25-A2的区别 |
LM3S2139-EQC25-A2T 德州仪器 | 类似代替 | LM3S2139-IQC25-A2和LM3S2139-EQC25-A2T的区别 |
