LM324SNG

LM324SNG 管装

The LM324S and LM2902S are low−cost, quad operational amplifiers with true differential inputs. They have several distinct advantages over standard operational amplifier types in single supply applications. The common mode input range includes the negative supply, thereby eliminating the necessity for external biasing components in many applications. The output voltage range also includes the negative power supply voltage.

Features

---

 |

.

Short Circuited Protected Outputs

.

True Differential Input Stage

.

Internally Compensated

.

Common Mode Range Extends to Negative Supply

.

Industry Standard Pinouts
