LMP7707MF/NOPB

TEXAS INSTRUMENTS  LMP7707MF/NOPB  芯片, 运算放大器, 15MHZ, 5.1V/uS, SOT-23-5

The is a single wide supply range precision Operational Amplifier with CMOS input, rail-to-rail input and output. The LMP7707 is part of the LMP precision amplifier family and is ideal for sensor interface and other instrumentation applications. This decompensated amplifier is stable at a gain of 6 and higher. The LMP7707 is built utilizing VIP50 technology, which allows the combination of a CMOS input stage and a supply voltage range of 12V with rail-to-rail common mode voltage capability. The LMP7707 is the perfect choice in many applications where conventional CMOS parts cannot operate due to the voltage conditions. The unique design of the rail-to-rail input stage of each of the LMP7707 significantly reduces the CMRR glitch commonly associated with rail-to-rail input amplifier.

.

Stable at a gain of 10 or higher

.

±200µV Maximum input offset voltage

.

±200fA Input bias current

.

9nV/√Hz Input voltage noise

.

130dB CMRR

.

130dB Open loop gain

.

715µA Supply current

.

Green product and no Sb/Br
