LM248DG4

IC OPAMP GP 1MHz 14SOIC

description/ordering information

The LM148, LM248, and LM348 are quadruple, independent, high-gain, internally compensated operational amplifiers designed to have operating characteristics similar to the µA741. These amplifiers exhibit low supply-current drain and input bias and offset currents that are much less than those of the µA741.

• µA741 Operating Characteristics

• Low Supply-Current Drain . . . 0.6 mA Typ per amplifier

• Low Input Offset Voltage

• Low Input Offset Current

• Class AB Output Stage

• Input/Output Overload Protection

• Designed to Be Interchangeable With Industry Standard LM148, LM248, and LM348
