TEXAS INSTRUMENTS LMC6036IM 运算放大器, 四路, 1.4 MHz, 4个放大器, 1.5 V/µs, 2V 至 15.5V, SOIC, 14 引脚
The is a low power CMOS quad Operational Amplifier capable of rail-to-rail output swing into loads of 600R. The 2.7V supply voltage corresponds to the end-of-life voltage 0.9V/cell for three NiCd or NiMH batteries in series, making the LMC6036 well suited for portable and rechargeable systems. It also features a well behaved decrease in its specifications at supply voltages below its ensured 2.7V operation. This provides a comfort zone for adequate operation at voltages significantly below 2.7V. Its ultra low input currents IIN makes it well suited for low power active filter application, because it allows the use of higher resistor values and lower capacitor values. In addition, the drive capability of the LMC6036 gives this op amp a broad range of applications for low voltage systems.
电源电压DC 2.70 V
输出电流 8mA @2.7V
供电电流 1.3 mA
电路数 4
通道数 4
针脚数 14
输入补偿漂移 2.30 µV/K
带宽 1.4 MHz
转换速率 1.50 V/μs
增益频宽积 1.4 MHz
输入补偿电压 500 µV
输入偏置电流 0.02 pA
工作温度Max 85 ℃
工作温度Min -40 ℃
增益带宽 1.4 MHz
共模抑制比Min 63 dB
电源电压 2V ~ 15.5V
电源电压Max 15.5 V
安装方式 Surface Mount
引脚数 14
封装 SOIC-14
封装 SOIC-14
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Each
RoHS标准 Non-Compliant
含铅标准 Contains Lead
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/06/15
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
LMC6036IM TI 德州仪器 | 当前型号 | 当前型号 |
LMC6036IMX 德州仪器 | 完全替代 | LMC6036IM和LMC6036IMX的区别 |
LMC6036IM/NOPB 德州仪器 | 类似代替 | LMC6036IM和LMC6036IM/NOPB的区别 |
LMC6036IMX/NOPB 德州仪器 | 类似代替 | LMC6036IM和LMC6036IMX/NOPB的区别 |
