LT1633CS

高速运算放大器 LT1633 - 45MHz, 45V/us, Quad Rail-to-Rail Input and Output Precision Op Amps

DESCRIPTION

The LT® 1632/LT1633 are dual/quad, rail-to-rail input and output op amps with a 45MHz gain-bandwidth product and a 45V/µs slew rate.

FEATURES

■ Gain-Bandwidth Product: 45MHz

■ Slew Rate: 45V/µs

■ Low Supply Current per Amplifier: 4.3mA

■ Input Common Mode Range Includes Both Rails

■ Output Swings Rail-to-Rail

■ Input Offset Voltage, Rail-to-Rail: 1350µV Max

■ Input Offset Current: 440nA Max

■ Input Bias Current: 2.2µA Max

■ Open-Loop Gain: 800V/mV Min

■ Low Input Noise Voltage: 12nV/√Hz Typ

■ Low Distortion: – 92dBc at 100kHz

■ Wide Supply Range: 2.7V to ±15V

■ Large Output Drive Current: 35mA Min

■ Dual in 8-Pin PDIP and SO Packages

APPLICATIONS

■ Active Filters

■ Rail-to-Rail Buffer Amplifiers

■ Driving A/D Converters

■ Low Voltage Signal Processing

■ Battery-Powered Systems
