STMICROELECTRONICS LY3200ALH 陀螺仪, MEMS, 模拟, 偏航, ± 2000°/s, 2.7 V, 3.6 V, LGA
The is an Adapter Board for standard DIL 24 socket. It is designed to facilitate the evaluation of MEMS devices. The board offers an effective solution for fast system prototyping and device evaluation directly within the users own application. The STEVAL-MKI076V1 can be plugged into a standard DIL 24 socket. The adapter provides the complete this pin-out and come ready-to-use with the required decoupling capacitors on the VDD power supply line.
- .
- Fully compatible with STEVAL-MKI109V2 motherboard
电源电压DC 2.70V min
供电电流 4.2 mA
针脚数 10
带宽 140 Hz
工作温度Max 85 ℃
工作温度Min -40 ℃
3dB带宽 140 Hz
电源电压 2.7V ~ 3.6V
电源电压Max 3.6 V
电源电压Min 2.7 V
引脚数 10
封装 TLGA-10
高度 1.1 mm
封装 TLGA-10
工作温度 -40℃ ~ 85℃ TA
产品生命周期 Not Recommended for New Designs
包装方式 Tray
制造应用 Industrial
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/12/17
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
LY3200ALH ST Microelectronics 意法半导体 | 当前型号 | 当前型号 |
LY3200ALHTR 意法半导体 | 功能相似 | LY3200ALH和LY3200ALHTR的区别 |
LY5150ALH 意法半导体 | 功能相似 | LY3200ALH和LY5150ALH的区别 |
LY5150ALHTR 意法半导体 | 功能相似 | LY3200ALH和LY5150ALHTR的区别 |
