0805 0.47 uF 6.3 V ±20 % 容差 X7R 低 ESL 单片 陶瓷电容
0.47µF ±20% 6.3V Ceramic Capacitor X7R 0805 2012 Metric
得捷:
CAP CER 0.47UF 6.3V X7R 0805
立创商城:
470nF ±20% 6.3V
e络盟:
多层陶瓷电容器, 表面贴装, 0.47 µF, 6.3 V, 0805 [2012 公制], ± 20%, X7R, LLM Series
艾睿:
Available with a variety of capacitance values, voltage ratings, package sizes, and other parameters, this LLM215R70J474MA11L multilayer ceramic capacitor from Murata can be used in multiple applications and for various purposes. It can withstand a voltage of 6.3 VDC. This MLCC capacitor has a maximum operating temperature of 125 °C. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery. It has a tolerance of 20%. Its capacitance value is 0.47uF. This product is 2 mm long, 0.5 mm tall and 1.25 mm deep.
安富利:
Cap Ceramic 0.47uF 6.3V X7R 20% SMD 0805 125°C Embossed T/R
Verical:
Cap Ceramic 0.47uF 6.3V X7R 20% Pad SMD 0805 125C T/R
额定电压DC 6.30 V
绝缘电阻 10 GΩ
电容 0.47 µF
容差 ±20 %
电介质特性 X7R
产品系列 LLM
工作温度Max 125 ℃
工作温度Min -55 ℃
额定电压 6.3 V
安装方式 Surface Mount
封装公制 2012
封装 0805
长度 2.00 mm
宽度 1.25 mm
高度 0.5 mm
封装公制 2012
封装 0805
厚度 0.5 mm
材质 X7R/-55℃~+125℃
工作温度 -55℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
最小包装 4000
制造应用 旁通,去耦
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
LLM215R70J474MA11L muRata 村田 | 当前型号 | 当前型号 |
LLA215R70J474MA14L 村田 | 类似代替 | LLM215R70J474MA11L和LLA215R70J474MA14L的区别 |
LLM215R70J474MA11K 村田 | 功能相似 | LLM215R70J474MA11L和LLM215R70J474MA11K的区别 |
