低电压轨到轨输出运算放大器 LOW-VOLTAGE RAIL-TO-RAIL OUTPUT OPERATIONAL AMPLIFIERS
DESCRIPON/ORDERING INFORMATION
The LMV821 single, LMV822 dual, and LMV824 quad devices are low-voltage 2.5 V to 5.5 V, low-power commodity operational amplifiers. Electrical characteristics are very similar to the LMV3xx operational amplifiers low supply current, rail-to-rail outputs, input common-mode range that includes ground. However, the LMV8xx devices offer a higher bandwidth 5.5 MHz typical and faster slew rate 1.9 V/μs typical.
FEATURES
• 2.5-V, 2.7-V, and 5-V Performance
• –40°C to 125°C Operation
• No Crossover Distortion
• Low Supply Current at VCC+ = 5 V:
– LMV821…0.3 mA Typ
– LMV822…0.5 mA Typ
– LMV824…1 mA Typ
• Rail-to-Rail Output Swing
• Gain Bandwidth of 5.5 MHz Typ at 5 V
• Slew Rate of 1.9 V/μs Typ at 5 V
