LMV7235M5

TEXAS INSTRUMENTS  LMV7235M5  模拟比较器, 轨至轨, 低功耗, 1, 45 ns, 2.7V 至 5.5V, SOT-23, 5 引脚

The is an ultra low power low voltage Comparator with open-drain/push-pull output. It is guaranteed to operate over the full supply voltage range of 2.7 to 5.5V. This device achieves a 75ns propagation delay while consuming only 65µA of supply current at 5V. It has a greater than rail-to-rail common mode voltage range. The input common mode voltage range extends 200mV below ground and 200mV above supply, allowing both ground and supply sensing. The LMV7235 features an open drain output. By connecting an external resistor, the output of the comparator can be used as a level shifter and a push-pull output stage. This feature allows operation without the need of an external pull-up resistor.

.

75ns Propagation delay

.

65µA Low supply current
