HDLS 系列限位开关HDLS 系列开关包含一个boss-and-socket头部,设计用于将头部牢固地固定到主体;独特的全金属驱动链提供一致的操作特性(即使在高温条件下);自提升压力板端子可节省接线时间。坚固外壳,静电环氧表面 操作端可旋转 90° 10 A 可修改侧面旋转样式,以用于顺时针和/或逆时针操作 应用包括食品和饮料、材料处理和传送设备 ### 认可UL, CSA, CE, CCC
HDLS 系列限位
HDLS 系列开关包含一个boss-and-socket头部,设计用于将头部牢固地固定到主体;独特的全金属驱动链提供一致的操作特性(即使在高温条件下);自提升压力板端子可节省接线时间。
坚固外壳,静电环氧表面
操作端可旋转 90°
10 A
可修改侧面旋转样式,以用于顺时针和/或逆时针操作
应用包括食品和饮料、材料处理和传送设备
### 认可
UL, CSA, CE, CCC
欧时:
限位开关,侧面旋转式,10A,IP67,1 NO,1NC,压铸锌,600Vac,
艾睿:
This heavy duty LSA1A limit switch from Honeywell can activate different components within your circuitry based on electro-mechanical connections within the switch. This device has a maximum current rating of 10 A @ 24VDC. It has a SPDT configuration. LSA1A is housed in zinc die cast. This limit switch has an operating temperature range of -12 °C to 121 °C. The LSA1A limit switch has a conduit termination style. This product is 41.1 mm long, 106.7 mm tall and 62 mm deep. The maximum DC voltage rating is 24 VDC.
Allied Electronics:
Limit Switch; SPDT; 600VAC; 10A; SideRotary; Silver Contacts; HDLS Series
Jameco:
Switch Limit N.O./N.C. Single Pole Double Throw SPDT Side Rotary Conduit 10A 24VDC Rotary Screw Mount Automotive
Chip1Stop:
Switch Limit N.O./N.C. SPDT Side Rotary Conduit 10A 24VDC Rotary Screw Mount Automotive
TME:
Limit switch; without lever; NO + NC; 10A; max240VAC; max240VDC
Verical:
Switch Limit N.O./N.C. SPDT Side Rotary Conduit 10A 24VDC Rotary Screw Mount Automotive
Newark:
Limit Switch, Side Rotary, SPDT-1NO, SPDT-NC, 10 A, 600 V, 0.45 N, HDLS Series
MASTER:
MICRO SWITCH™ Heavy-Duty Limit Switches: HDLS Series, Epoxy-Coated Zinc Housing, Side Rotary, Momentary, No Lever, 1NC 1NO Single Pole Double Throw SPDT Snap Action, Double Break, AC 15, A600; DC 13, R300, 0.5 in - 14 NPT Conduit, Plug-In, Operating Tem
Online Components:
MICRO SWITCH™ Heavy-Duty Limit Switches: HDLS Series, Epoxy-Coated Zinc Housing, Side Rotary, Momentary, No Lever, 1NC 1NO Single Pole Double ...
GOPHER:
Enclosed Limit Switch SPDT 10 AMP SIDE MOUNT SCREW TERMINAL PLUG IN;FIXED SIDE ROLLER LEVER, 1/2-14 NPT THREA MICRO SWITCH
Electro Sonic:
MICRO SWITCH™ Heavy-Duty Limit Switches: HDLS Series, Epoxy-Coated Zinc Housing, Side Rotary, Momentary, No Lever, 1NC 1NO Single Pole Double ...
额定电压DC 115 V
接触器类型 Side Rotary
额定电压AC 120 V
额定电流 10 A
触点类型 SPDT
触点额定电流 10.0 A
额定电流Max 10A @24VDC
工作温度Max 121 ℃
工作温度Min -12 ℃
额定电压 600 VAC
安装方式 Plug In
封装 600
长度 41.15 mm
宽度 61.9 mm
高度 106.78 mm
封装 600
工作温度 -20℃ ~ 121℃
外壳材质 Zinc Die-Cast
产品生命周期 Active
制造应用 Sensing & Instrumentation, Industrial, Sensing & Instrumentation, Industrial
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
ECCN代码 EAR99
HTS代码 8536509055
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
LSA1A Honeywell 霍尼韦尔 | 当前型号 | 当前型号 |
LSA3K 霍尼韦尔 | 类似代替 | LSA1A和LSA3K的区别 |
LSA6B 霍尼韦尔 | 功能相似 | LSA1A和LSA6B的区别 |
LSA2B 霍尼韦尔 | 功能相似 | LSA1A和LSA2B的区别 |
