TEXAS INSTRUMENTS LMV393IPWR 模拟比较器, 双路, 通用, 2, 300 ns, 2.7V 至 5.5V, TSSOP, 8 引脚
The is a dual general purpose Low-Voltage Comparator operates from 5 to 30V. It is suitable for applications where low-voltage operation, low power and space saving are the primary specifications in circuit design. This device offers specifications that meet or exceed the familiar LM339 and LM393 devices at a fraction of the supply current.
电源电压DC 2.70V min
输出电流 84mA @5V
供电电流 0.2 mA
电路数 2
通道数 2
针脚数 8
静态电流 70.0 µA
输入补偿电压 7 mV
输入偏置电流 250 nA
工作温度Max 125 ℃
工作温度Min -40 ℃
电源电压 2.7V ~ 5.5V
电源电压Max 5.5 V
电源电压Min 2.7 V
安装方式 Surface Mount
引脚数 8
封装 TSSOP-8
封装 TSSOP-8
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
制造应用 工业, 测试与测量, 传感与仪器
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/06/15
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
LMV393IPWR TI 德州仪器 | 当前型号 | 当前型号 |
LMV393IPWRG4 德州仪器 | 完全替代 | LMV393IPWR和LMV393IPWRG4的区别 |
LMV393IPWRE4 德州仪器 | 完全替代 | LMV393IPWR和LMV393IPWRE4的区别 |
LMV393IPW 德州仪器 | 类似代替 | LMV393IPWR和LMV393IPW的区别 |
