100mA,STMicroelectronicsL78L 系列三端子正调节器嵌入内部电流限制和热关闭。 提供充足的散热片,可提供高达 100mA 的输出电流。### 线性电压稳压器,STMicroelectronics
线性稳压器,100mA,STMicroelectronics
L78L 系列三端子正调节器嵌入内部电流限制和热关闭。 提供充足的散热片,可提供高达 100mA 的输出电流。
### 线性电压稳压器,STMicroelectronics
欧时:
### 线性稳压器,100mA,STMicroelectronicsL78L 系列三端子正调节器嵌入内部电流限制和热关闭。 提供充足的散热片,可提供高达 100mA 的输出电流。### 线性电压稳压器,STMicroelectronics
得捷:
IC REG LINEAR 3.3V 100MA 8SO
e络盟:
线性稳压器, 固定, 8.3V至30V输入, 3.3V/100mA输出, SOIC-8
艾睿:
Use this standard L78L33CD-TR linear regulator from STMicroelectronics to vary your voltage levels to your desired level. Its typical dropout voltage at current is 1.7@40mA V. It has an overall accuracy of ±8 %. This voltage regulation device&s;s single output can produce a current up to 0.1 A. This will operate at a maximum voltage of 30 V, making it easy to control the power in your circuit. With a fixed output that has a voltage of 3.3 V, this is power management at its best. Operate at a constant current by utilizing the load regulation of 60mV and line regulation of 150mV. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery. Its polarity is positive. This voltage regulation device has an operating temperature range of 0 °C to 125 °C.
安富利:
Standard Regulator Pos 3.3V 0.1A 8-Pin SO N T/R
Chip1Stop:
Standard Regulator Pos 3.3V 0.1A 8-Pin SO N T/R
Verical:
Standard Regulator Pos 3.3V 0.1A 8-Pin SO N T/R
输出接口数 1
输入电压DC 30.0V max
输出电压 3.3 V
输出电流 100 mA
供电电流 5.5mA ~ 6mA
针脚数 8
静态电流 6 mA
跌落电压 1.7V @40mA
输入电压Max 30 V
输入电压Min 8.3 V
输出电压Min 3.3 V
输出电流Max 0.1 A
工作温度Max 125 ℃
工作温度Min 0 ℃
精度 ±8 %
输入电压 30 V
安装方式 Surface Mount
引脚数 8
封装 SOIC-8
长度 5 mm
宽度 4 mm
高度 1.65 mm
封装 SOIC-8
工作温度 0℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
L78L33CD-TR ST Microelectronics 意法半导体 | 当前型号 | 当前型号 |
L78L33CD 意法半导体 | 完全替代 | L78L33CD-TR和L78L33CD的区别 |
