100mA,STMicroelectronicsL78L 系列三端子正调节器嵌入内部电流限制和热关闭。 提供充足的散热片,可提供高达 100mA 的输出电流。### 线性电压调节器,STMicroelectronics
线性稳压器,100mA,STMicroelectronics
L78L 系列三端子正调节器嵌入内部电流限制和热关闭。 提供充足的散热片,可提供高达 100mA 的输出电流。
得捷:
IC REG LINEAR 6V 100MA SOT89-3
立创商城:
正 Vin=30V Vout=6V 100mA 46dB@120Hz
欧时:
### 线性电压调节器,100mA,STMicroelectronicsL78L 系列三端子正调节器嵌入内部电流限制和热关闭。 提供充足的散热片,可提供高达 100mA 的输出电流。### 线性电压调节器,STMicroelectronics
贸泽:
Linear Voltage Regulators 6.0V 0.1A Positive
e络盟:
线性稳压器, 固定, 12V至30V输入, 6V/100mA输出, SOT-89-3
艾睿:
This standard L78L06ACUTR linear regulator from STMicroelectronics gives you control over the voltage levels of your circuit. Its typical dropout voltage at current is 1.7@40mA V. It has an overall accuracy of ±4 %. This voltage regulation device&s;s single output can produce a current up to 0.1 A. The best way to provide power to your application is by using this, which needs a voltage lower than 30 V. With a fixed output that has a voltage of 6 V, this is power management at its best. Operate at a constant current by utilizing the load regulation of 60mV and line regulation of 150mV. In order to guarantee safe delivery and allow for quick mounting of this component after delivery, it will be enclosed in tape and reel packaging during shipment. This voltage regulation device has a minimum operating temperature of 0 °C and a maximum of 125 °C. Its polarity is positive.
安富利:
Standard Regulator Pos 6V 0.1A 4-Pin3+Tab SOT-89 T/R
富昌:
L78L Series 100 mA 6 V Fixed Three Terminal Voltage Regulator - SOT-89
Chip1Stop:
Standard Regulator Pos 6V 0.1A 4-Pin3+Tab SOT-89 T/R
Verical:
Standard Regulator Pos 6V 0.1A 4-Pin3+Tab SOT-89 T/R
DeviceMart:
IC REG LDO 6V .1A SOT-89
Win Source:
Linear Voltage Regulator IC Positive Fixed 1 Output 6V 100mA SOT-89-3
输出接口数 1
输入电压DC 30.0V max
输出电压 6 V
输出电流 100 mA
供电电流 5.5mA ~ 6mA
针脚数 3
静态电流 6 mA
跌落电压 1.7V @40mA
输入电压Max 30 V
输入电压Min 30 V
输出电压Min 6 V
输出电流Max 100 mA
工作温度Max 150 ℃
工作温度Min 0 ℃
精度 ±4 %
输入电压 30 V
安装方式 Surface Mount
引脚数 4
封装 SOT-89-3
长度 4.6 mm
宽度 2.6 mm
高度 1.6 mm
封装 SOT-89-3
工作温度 0℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
香港进出口证 NLR
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
L78L06ACUTR ST Microelectronics 意法半导体 | 当前型号 | 当前型号 |
L78L06ABUTR 意法半导体 | 类似代替 | L78L06ACUTR和L78L06ABUTR的区别 |
UA78L06ACPK 德州仪器 | 功能相似 | L78L06ACUTR和UA78L06ACPK的区别 |
UA78L06ACPKG3 德州仪器 | 功能相似 | L78L06ACUTR和UA78L06ACPKG3的区别 |
