LTC1863IGN#PBF

LINEAR TECHNOLOGY  LTC1863IGN#PBF  模数转换器, 八路微功率, 12 bit, 200 kSPS, 单, 4.75 V, 5.25 V, SSOP

The is a 12-bit Analog-to-digital Converter ADC with serial I/O and an internal reference. The ADC typically draws only 1.3mA from a single 5V supply. The 8-channel input multiplexer can be configured for either single-ended or differential inputs or unipolar or bipolar conversions. The automatic nap and sleep modes benefit power sensitive applications. It can be used in space-sensitive as well as low-power applications.

.

Single-ended or differential inputs

.

Unipolar or bipolar conversion modes

.

SPI/MICROWIRE compatible serial I/O

.

On-chip or external reference

.

Sleep mode

.

Automatic nap mode between conversions
