L79L15ACUTR

STMicroelectronics标准负电压调节器提供非常稳定且可靠的操作，具有短路和热过载保护。 适用于多种电压调节应用。### 线性电压稳压器，STMicroelectronics

负线性电压稳压器，STMicroelectronics

标准负电压调节器提供非常稳定且可靠的操作，具有短路和热过载保护。 适用于多种电压调节应用。

得捷:
IC REG LINEAR -15V 100MA SOT89-3

立创商城:
L79L15ACUTR

欧时:
### 负线性电压稳压器，STMicroelectronics标准负电压调节器提供非常稳定且可靠的操作，具有短路和热过载保护。 适用于多种电压调节应用。### 线性电压稳压器，STMicroelectronics

贸泽:
Linear Voltage Regulators 15V 0.1A Negative

e络盟:
线性稳压器, 固定, -35V至-23V输入, -15V/100mA输出, SOT-89-3

艾睿:
Stable voltages are always needed for sensitive systems implement this standard L79L15ACUTR linear regulator from STMicroelectronics. Its typical dropout voltage at current is 1.7@40mA V. It has an overall accuracy of ±5 %. This voltage regulation device&s;s single output can produce a current up to 0.1 A. The best way to provide power to your application is by using this, which needs a voltage lower than -35 V. With a fixed output that has a voltage of -15 V, this is power management at its best. Operate at a constant current by utilizing the load regulation of 150mV and line regulation of 300mV. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. This voltage regulation device has an operating temperature range of 0 °C to 125 °C. Its polarity is negative.

安富利:
Standard Regulator Neg -15V 0.1A 4-Pin3+Tab SOT-89 T/R

Verical:
Standard Regulator Neg -15V 0.1A 4-Pin3+Tab SOT-89 T/R

Win Source:
Negative voltage regulators
