LD1117ADT12TR

1A，STMicroelectronicsLD1117A 是低压降电压调节器，提供高达 1A 的输出电流，具有内部电流和热限制。### 线性电压调节器，STMicroelectronics

线性电压稳压器，1A，STMicroelectronics

LD1117A 是低压降电压调节器，提供高达 1A 的输出电流，具有内部电流和热限制。

### 线性电压稳压器，STMicroelectronics

得捷:
IC REG LINEAR 1.2V 1A DPAK

立创商城:
LD1117ADT12TR

欧时:
### 线性电压稳压器，1A，STMicroelectronicsLD1117A 是低压降电压调节器，提供高达 1A 的输出电流，具有内部电流和热限制。### 线性电压调节器，STMicroelectronics

贸泽:
LDO Voltage Regulators Lo drop fixed adjust pos Vltg reg

e络盟:
固定LDO稳压器, 最高10V, 1.15V压降, 1.2V/1.2A输出, TO-252-3

艾睿:
This LDO LD1117ADT12TR linear regulator developed by STMicroelectronics keeps the power stable! Its typical dropout voltage at current is 1@100mA|1.05@500mA|1.15@1A V. This device has a maximum power dissipation of 12000 mW. It has an overall accuracy of ±2 %. This voltage regulation device&s;s single output can produce a current up to 1.2Typ A. It only needs a voltage that does not exceed 10 V to effectively power your circuit. With a fixed output that has a voltage of 1.2 V, this is power management at its best. Your circuit has the capability to produce a constant current at its output by using a load regulation of 10mV and line regulation of 6mV. Its maximum power dissipation is 12000 mW. This component will be shipped in tape and reel packaging for effective mounting and safe delivery. Its polarity is positive. This voltage regulation device has a minimum operating temperature of 0 °C and a maximum of 125 °C. The maximum dropout voltage is 1.1@100mA|1.15@500mA|1.3@1A V.

安富利:
LDO Regulator Pos 1.2V 1.2A 3-Pin2+Tab DPAK T/R

富昌:
LD1117 Series 1 A 1.2 V Fixed Output Positive Voltage LDO Regulator TO-252

Verical:
LDO Regulator Pos 1.2V 1.2A 3-Pin2+Tab DPAK T/R

DeviceMart:
IC REG LDO 1.2V 1.2A D-PAK

Win Source:
Linear Voltage Regulator IC Positive Fixed 1 Output 1.2V 1A D-Pak
