具有旁路和使能功能的 150mA、低压降稳压器 5-SOT-23 -40 to 125
Linear Voltage Regulator IC 1 Output 150mA SOT-23-5
得捷:
IC REG LINEAR 5V 150MA SOT23-5
立创商城:
LP3985IM5X-5.0/NOPB
德州仪器TI:
150-mA, low-dropout voltage regulator with bypass & enable
贸泽:
LDO Voltage Regulators MicroPwr 150mA LDO CMOS Vtg Reg
艾睿:
Use the LDO LP3985IM5X-5.0/NOPB linear regulator from Texas Instruments to maintain a constant output voltage. This device has a maximum power dissipation of 250 mW. It has an overall accuracy of ±2 %. Its typical dropout voltage at current is 0.0004@1mA|0.02@50mA|0.045@100mA|0.06@150mA V. This voltage regulation device&s;s single output can produce a current up to 0.15 A. The best way to provide power to your application is by using this, which needs a voltage of at least 2.5 V and no higher than 6 V. With a fixed output that has a voltage of 5 V, this is power management at its best. Its maximum power dissipation is 250 mW. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components. Its polarity is positive. This voltage regulation device has a minimum operating temperature of -40 °C and a maximum of 125 °C. The maximum dropout voltage is 0.002@1mA|0.035@50mA|0.07@100mA|0.1@150mA V.
安富利:
LDO Regulator Pos 5V 0.15A 5-Pin SOT-23 T/R
Chip1Stop:
LDO Regulator Pos 5V 0.15A 5-Pin SOT-23 T/R
Verical:
LDO Regulator Pos 5V 0.15A 5-Pin SOT-23 T/R
Win Source:
Linear Voltage Regulator IC Positive Fixed 1 Output 5V 150mA SOT-23-5
输出接口数 1
输出电压 5 V
输出电流 150 mA
耗散功率 250 mW
静态电流 85.0 µA
输出电容类型 Ceramic
跌落电压 0.06V @150mA
调节输出数 1
输入电压Max 6 V
输入电压Min 2.5 V
输出电压Min 5 V
输出电流Max 0.15 A
工作温度Max 125 ℃
工作温度Min -40 ℃
耗散功率Max 250 mW
精度 ±2 %
输入电压 ≤6 V
安装方式 Surface Mount
引脚数 5
封装 SOT-23-5
封装 SOT-23-5
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
LP3985IM5X-5.0/NOPB TI 德州仪器 | 当前型号 | 当前型号 |
LP3985IM5-5.0/NOPB 德州仪器 | 类似代替 | LP3985IM5X-5.0/NOPB和LP3985IM5-5.0/NOPB的区别 |
LP3985IM5X-5.0 德州仪器 | 类似代替 | LP3985IM5X-5.0/NOPB和LP3985IM5X-5.0的区别 |
