LTC2250CUH#PBF

LINEAR TECHNOLOGY  LTC2250CUH#PBF  模数转换器, 10 bit, 105 MSPS, 单, 2.85 V, 3.5 V, QFN

The is a 10-bit low noise Analog-to-digital Converter ADC designed for digitizing high frequency, wide dynamic range signals. The converter is perfect for demanding imaging and communications applications with AC performance that includes 61.6dB SNR and 85dB SFDR for signals at the Nyquist frequency. A single 3V supply allows low power operation. A separate output supply allows the outputs to drive 0.5 to 3.3V logic. A single-ended CLK input controls converter operation. An optional clock duty cycle stabilizer allows high performance at full speed for a wide range of clock duty cycles.

.

No missing codes

.

Flexible input - 1VP-P to 2VP-P range

.

Clock duty cycle stabilizer

.

Shutdown and nap modes

.

Pin-compatible 10-bit version
