LINEAR TECHNOLOGY LTC1403AIMSE#PBF 模数转换器, 14 bit, 2.8 MSPS, 单, 2.7 V, 3.6 V, MSOP
Do you need to perform calculations on real world physical signals such as light or temperature? Then use this ADC from to convert those analog signals to digital data that a computer can read! Its maximum power dissipation is 100 mW. This device"s digital interface is serial 3-wire, spi. This device is based on SAR architecture. It has a single-ended and differential input signal. This ADC has a resolution of 14bit. This ADC has an input voltage of 2.5 V. This ADC has a minimum operating temperature of -40 °C and a maximum of 85 °C.
电源电压DC 2.70V min
工作电压 2.7V ~ 3.6V
电路数 1
通道数 1
针脚数 10
位数 14
耗散功率 12 mW
采样率 2.8 Msps
模数转换数ADC 1
输入数 1
工作温度Max 85 ℃
工作温度Min -40 ℃
耗散功率Max 100 mW
输入通道数 1
电源电压Max 3.6 V
电源电压Min 2.7 V
输入电压 2.5 V
安装方式 Surface Mount
引脚数 10
封装 MSOP-10
封装 MSOP-10
工作温度 -40℃ ~ 85℃
产品生命周期 Unknown
包装方式 Each
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/12/17
ECCN代码 EAR99
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
LTC1403AIMSE#PBF Linear Technology 凌力尔特 | 当前型号 | 当前型号 |
LTC1403AIMSE#TRPBF 凌力尔特 | 完全替代 | LTC1403AIMSE#PBF和LTC1403AIMSE#TRPBF的区别 |
LTC1403ACMSE#TRPBF 凌力尔特 | 完全替代 | LTC1403AIMSE#PBF和LTC1403ACMSE#TRPBF的区别 |
LTC1403ACMSE#PBF 凌力尔特 | 类似代替 | LTC1403AIMSE#PBF和LTC1403ACMSE#PBF的区别 |
