LDO(低压降)线性电压调节器,150mA,2.0V 至 2.9V,Texas Instruments### LDO(低压降)线性电压调节器,Texas Instruments低压降或 LDO 为线性电压稳压器。 我们有多种系列的线性稳压器。 LDO 稳压器可在输入 - 输出差分电压较小时运行。 LDO 电压稳压器可提供快速瞬态响应、宽输入电压范围、低静态电流、低噪声、高 PSRR。
LDO(低压降)线性稳压器,150mA,2.0V 至 2.9V,Texas Instruments
### LDO(低压降)线性稳压器,Texas Instruments
低压降或 LDO 为线性电压稳压器。 我们有多种系列的线性稳压器。 LDO 稳压器可在输入 - 输出差分电压较小时运行。 LDO 电压稳压器可提供快速瞬态响应、宽输入电压范围、低静态电流、低噪声、高 PSRR。
立创商城:
LP5951MG-2.0/NOPB
德州仪器TI:
150-mA, low-IQ, low-dropout voltage regulator with enable
得捷:
IC REG LINEAR 2V 150MA SC70-5
欧时:
Texas Instruments LP5951MG-2.0/NOPB LDO 稳压器, 2 V输出, 150mA最大输出, 3.5%精确度, 1.8 → 5.5 V输入
艾睿:
If you need to maintain a steady voltage on your circuit, then this LDO LP5951MG-2.0/NOPB linear regulator from Texas Instruments is perfect for you! Its typical dropout voltage at current is 0.2@150mA V. It has an overall accuracy of ±2 %. This voltage regulation device&s;s single output can produce a current up to 0.15 A. This will operate at a minimum voltage of 1.8 V and a maximum voltage of 5.5 V, making it easy to control the power in your circuit. With a fixed output that has a voltage of 2 V, this is power management at its best. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery. This voltage regulation device has an operating temperature range of -40 °C to 125 °C. The maximum dropout voltage is 0.35@150mA V. Its polarity is positive.
安富利:
LDO Regulator Pos 2V 0.15A 5-Pin SC-70 T/R
Verical:
LDO Regulator Pos 2V 0.15A 5-Pin SC-70 T/R
输出接口数 1
输入电压DC 5.50V max
输出电压 2 V
输出电流 150 mA
静态电流 0.07 mA
输出电容类型 Ceramic
跌落电压 0.2V @150mA
调节输出数 1
输入电压Max 5.5 V
输入电压Min 1.8 V
输出电流Max 150 mA
工作温度Max 125 ℃
工作温度Min -40 ℃
精度 ±2 %
输入电压 ≤5.5 V
安装方式 Surface Mount
引脚数 5
封装 SC-70-5
长度 2 mm
宽度 1.25 mm
高度 0.9 mm
封装 SC-70-5
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
LP5951MG-2.0/NOPB TI 德州仪器 | 当前型号 | 当前型号 |
LP5951MG-2.0 德州仪器 | 类似代替 | LP5951MG-2.0/NOPB和LP5951MG-2.0的区别 |
LP5951MGX-2.0/NOPB 德州仪器 | 类似代替 | LP5951MG-2.0/NOPB和LP5951MGX-2.0/NOPB的区别 |
