LP2951CMMX/NOPB

LP2950 -N / LP2951 -N系列的可调微功耗电压调节器 LP2950-N/LP2951-N Series of Adjustable Micropower Voltage Regulators

PMIC - 稳压器 - 线性 输出 100mA 8-VSSOP

得捷:
IC REG LIN POS ADJ 100MA 8VSSOP

立创商城:
LP2951CMMX/NOPB

德州仪器TI:
100-mA, 30-V, low-dropout voltage regulator with power good & enable

艾睿:
This LDO LP2951CMMX/NOPB linear regulator developed by Texas Instruments keeps the power stable! Its typical dropout voltage at current is 0.05@100uA|0.38@100mA V. It has an overall accuracy of ±0.5Typ %. This voltage regulation device&s;s single output can produce a current up to 0.1 A. By working with a maximum input voltage of 30 V, this is the best way to control the power in your circuit. With an adjustable output that has a voltage of 1.24 to 29 V, this is power management at its best. At a load regulation of 0.1% and line regulation of 0.1% a constant current can be produced at the output of your circuit. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. This voltage regulation device has a minimum operating temperature of -40 °C and a maximum of 125 °C. The maximum dropout voltage is 0.08@100uA|0.45@100mA V. Its polarity is positive.

安富利:
LDO Regulator Pos 1.24V to 29V 0.1A 8-Pin MSOP T/R

Verical:
LDO Regulator Pos 1.24V to 29V 0.1A 8-Pin VSSOP T/R

DeviceMart:
IC REG LDO ADJ .1A 8-MSOP

Win Source:
Linear Voltage Regulator IC Positive Fixed or Adjustable 1 Output 5V, 1.24 V ~ 29 V 100mA 8-VSSOP
