低压差稳压器 300-mA LDO for Digital Applications 4-DSBGA
PMIC - 稳压器 - 线性 输出 300mA 4-DSBGA(1x1)
得捷:
IC REG LINEAR 1.8V 300MA 4DSBGA
立创商城:
LP3991TL-1.8/NOPB
德州仪器TI:
300-mA, low-dropout voltage regulator with enable
贸泽:
低压差稳压器 300-mA LDO for Digital Applications 4-DSBGA
艾睿:
Never worry about components not turning off and on due to lack of voltage with this LDO LP3991TL-1.8/NOPB linear regulator from Texas Instruments. It has an overall accuracy of ±1 %. Its typical dropout voltage at current is 0.055@150mA|0.11@300mA V. This voltage regulation device&s;s single output can produce a current up to 0.3 A. Supply your circuit with sufficient power by implementing this, which requires a minimum input voltage of 1.65 V that does not exceed 4 V. With a fixed output that has a voltage of 1.8 V, this is power management at its best. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery. The maximum dropout voltage is 0.09@150mA|0.18@300mA V. Its polarity is positive. This voltage regulation device has a minimum operating temperature of -40 °C and a maximum of 85 °C.
Verical:
LDO Regulator Pos 1.8V 0.3A 4-Pin DSBGA T/R
Win Source:
Linear Voltage Regulator IC Positive Fixed 1 Output 1.8V 300mA 4-DSBGA
容差 ±3 %
输出接口数 1
输出电压 1.8 V
输出电流 300 mA
供电电流 100µA ~ 225µA
静态电流 50.0 µA
输出电容类型 Ceramic
跌落电压 0.055V @150mA,0.11V @300mA
调节输出数 1
输入电压Max 4 V
输入电压Min 1.65 V
输出电压Min 1.8 V
输出电流Max 0.3 A
工作温度Max 85 ℃
工作温度Min -40 ℃
精度 ±1 %
输入电压 ≤4 V
安装方式 Surface Mount
引脚数 4
封装 WFBGA-4
封装 WFBGA-4
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
LP3991TL-1.8/NOPB TI 德州仪器 | 当前型号 | 当前型号 |
LP3991TLX-1.8/NOPB 德州仪器 | 类似代替 | LP3991TL-1.8/NOPB和LP3991TLX-1.8/NOPB的区别 |
