非常低压降稳压器与抑制 Very low drop voltage regulators with inhibit
PMIC - 稳压器 - 线性 正 固定 1 输出 100mA TO-92-3
得捷:
IC REG LINEAR 3.3V 100MA TO92-3
立创商城:
具有抑制功能的极低压降电压稳压器
e络盟:
固定LDO稳压器, 最高18V, 200mV压降, 3.3V/150mA输出, TO-92-3
艾睿:
This LDO LE33CZ-AP linear regulator developed by STMicroelectronics keeps the power stable! It has an overall accuracy of ±2 %. Its typical dropout voltage at current is 0.2@100mA V. This voltage regulation device&s;s single output can produce a current up to 0.1 A. It only needs a voltage that does not exceed 18 V to effectively power your circuit. With a fixed output that has a voltage of 3.3 V, this is power management at its best. A load regulation of 25mV and line regulation of 20mV is necessary for providing a constant voltage level at your output. Its polarity is positive. This voltage regulation device has a minimum operating temperature of -40 °C and a maximum of 125 °C. The maximum dropout voltage is 0.4@100mA V.
安富利:
LDO Regulator Pos 3.3V 0.1A 3-Pin TO-92 Ammo
Chip1Stop:
LDO Regulator Pos 3.3V 0.1A 3-Pin TO-92 Ammo
Verical:
LDO Regulator Pos 3.3V 0.1A 3-Pin TO-92 T/R
Win Source:
IC REG LDO 3.3V 0.1A TO92-3
输出接口数 1
输入电压DC 18.0V max
输出电压 3.3 V
输出电流 100 mA
供电电流 1mA ~ 3mA
针脚数 3
跌落电压 0.2V @100mA
输入电压Max 18 V
输出电压Min 3.3 V
输出电流Max 0.1 A
工作温度Max 125 ℃
工作温度Min -40 ℃
精度 ±2 %
输入电压 18 V
安装方式 Through Hole
引脚数 3
封装 TO-92-3
封装 TO-92-3
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
LE33CZ-AP ST Microelectronics 意法半导体 | 当前型号 | 当前型号 |
LE33CZ-TR 意法半导体 | 完全替代 | LE33CZ-AP和LE33CZ-TR的区别 |
LE33ABZ 意法半导体 | 完全替代 | LE33CZ-AP和LE33ABZ的区别 |
LE50CZ 意法半导体 | 类似代替 | LE33CZ-AP和LE50CZ的区别 |
